How to Order A Right NLO Crystal

Angle Tilting

In order to obtain maximum conversion efficiency, angle tilting is normally used to reach hase-matching direction. There are two axes for tilting crystal angles as shown in the right figure. Because the NLO crystals provided by JYS are normally cut in a principal crystal plane, conversion efficiency isn't sensitive to the angle tilting
around n-axis. However, it is very sensitive to the angle tilting around m-axis which is called tilting axis of NLO crystals and is normal to marked surface. Customers have to pay great attention when rotating the crystal around m- axis. A crystal mount with angle accuracy of about 5 arc second is recommended.

Optimum Crystal Size and Cut When ordering a nonlinear optical crystal, crystal orientation (or crystal cut) and size have to be known. The orientation is solely determined by the nonlinear optical process. For example, for type I frequency-doubling of 1.064mm, BBO is cut at q = 22.8° and f = 0°. Where:q is the polar angle between the optical axis and the propagation direction, f is the azimuthal angle between the projection of propagation direction onto the XY plane and the X axis. If you aren't sure about the crystal orientation and merely provide the nonlinear optical process of your application, JYS's salesmen and engineers will help you.

The crystal size is divided into three dimensions, Width(W), Heigth(H) 3 and Length(L), which is common written as W x H x L mm . The careful design of crystal size is important because the price of crystal varies from crystal sizes. More important, the conversion efficiency has direct relation to crystal length.

To select the optimum crystal height (H), the laser beam diameter upon the crystal should be taken into account. The optimum crystal height should be slightly (for instance, 1 mm to 2mm) larger than the laser beam diameter upon the crystal.

Both of laser beam diameter upon NLO crystal and tunable wavelength range have to be considered when designing the optimum crystal width (W). If it is a single NLO process, for example, frequency doubling 532 nm, we select W = H. If it is wide wavelength tuning NLO process, for example, frequency doubling a Dye laser from 44° nm to 66° nm by using BBO crystal, the crystal should be tuned from q = 36° to q = 66.6°. The width (W) is set to H + 2xtg((66.6°- 36°)/2)xL. Because if the crystal height (H) is 4mm and length (L) is 7 mm, the W should be approximately 8 mm long.

Every NLO crystal has a standard length (L) for frequency doubling lasers with pulse width longer than nanosecond (ns). For example, the standard crystal lengths for BBO and KTP are 7 mm and 5 mm, respectively. However, OPO and OPA need longer length, for example, > 12 mm for BBO, and the SHG and THG of ultrashort pulse lasers use thin crystals with length of less than 1 mm. JYS's salesmen and engineers collected a series of standard crystal lengths for various applications. This information is provided free.

Brewster's angle NLO crystals

For laser beam propagates from Air to NLO crystal (with refractiveindices n). Brewster's angle is defined as qB=arctan(n). At Brewster's angle, the surface reflectance is zero for the light with polarization inside the plane defined by the direction of light propagation and the normal to the surface.

In order to have a low surface reflection, Brewster's angle cut (B-cut) NLO crystals are used. Without special notices, JYS will fabricate the standard B-cut crystals according to the enclosed drawing. If customers design different sketch from our standard one, please notify JYS by giving us a drawing

What is the Marked Surface:

The surface consists of Z, the optical axis and K, the light propagation direction is called as main plane. JYS’s NLO crystals are dot marked on the crystal surface which parallel the optical axis and main plane. As shown as the drawing. The dot marked surface is called marked surafce.

Meanwhile, if the coating is different on the input and output surface, there is an arrow mark on the crystal side surface, which direct from input surface to output surface.

How to handle a NLO crystal

When you receive crystals from JYS, please make sure that only qualified personnel are able to open inner plastic boxes at clean environment. When the plastic box of a NLO crystal is opened, please prevent finger print, oil and other substances from adhering to the polished or coated surfaces.

If the surfaces are contaminated, please blow the surfaces with air ball. If there is still pollution on the crystal surfaces, please clean the surfaces with cleaning liquid and soft silk. For BBO crystal, the mixing liquid of 50% high purity alcohol and 50% high purity ether is recommended as cleaning liquid. Please notify that the contaminated surfaces are very easy to be damaged.

Some NLO crystals have a low susceptibility to moisture, you are advised to provide dry atmosphere conditions for both use and preservation of them. When polished surfaces are fogged or damaged, please ask JYS for repolishing and coating service.
