Coating Overview
Description
JYS can provide a wide variety of coatings from simple single layer AR coatings using Mg F2 and mirror coatings to complex multilayer dielectric stacks. Typical types of dielectric coatings are BBAR, V-coatings, Dual wavelength AR coatings and HR coatings. Sharp cut-on and cut-off filters are also available.
Please contact us, if our standard coatings described in this chapter can not meet your requirements. Our engineers can design a special coating for you.
|
Coating Type
|
Properties and Application
|
|
|
Antireflection
|
Single Layer MgF2
|
Applied to materials with refractive indices from 1.45 to 2.4. The most popular antireflection coating for visible. They are insensitive to change in incidence angles.
|
|
Multilayer "V"
|
Used to provide low reflectance with in a narrow durable wavelength band for most laser application. Minimum reflection can be less than 0.1%
|
|
|
Broadband Multilayer
|
These coatings have excellent performance over a broad spectral range broadband. Coating performance is sensitive to angle of incidence.
|
|
|
Dual Wavelength Band
|
Offer very low reflectance at two widely spaced wavelengths, such as Nd:YAG Laser (1064) and its second harmonic (532) . JYS makes this a double wavelength waveplate.
|
|
|
Partial Reflection
|
Narrow Band
|
Provide 50% reflection and transmission at an angle of 45° incidence for a single wavelength. Perfect for beamsplitters application. Transmission/reflection (T/R) ratio of 20/80, or others for Beamsplitter is available upon request.
|
|
Broadband
|
Over a wide bandwidth provides 50% reflection and transmission. JYS can also provide coatings with different R/T ratios at and specific angle of incident.
|
|
|
Beamsplitter
|
Laser Line Polarization Beamsplitter
|
High reflection for s-polarized and antireflection for p-polarized for laser application.
|
|
Broadband Polarization Beamsplitter
|
Wide wavelength bandwidth provide high reflection to s-polarized and antiflection to p-polarized
|
|
|
Dichroic Beamsplitters Mirrors
|
These coatings can separate the laser fundamental and the pump wavelength, or the fundamental and the second harmonic. They are specific applied to laser mirror.
|
|
|
High Reflection
|
Dielectric High Reflective Coatings
|
Provide high reflectance over a broad bandwidth, and is ideal for a tunable laser or in white light applications.
|
|
Metallic High Reflective Coatings
|
Metallic coatings have low peak reflectance, mechanical durability and damage threshold, but they have extremely broadband and low cost. They are insensitivity to angle of incident light and polarization.
|
|
